      Home>Product

      • Grooving Angle:120o
      • The Width Of Sheet:30mm-120mm
      • Input Voltage:AC380/50Hz
      • Weight:500kg
      • Power:2.1Kw
      • Specification:1050mmX1000mmX1200mm
      • Working Thickness:0.5mm-1.5mm
      • Suitable Metal Sheet:
      • Stainless Steel,Iron Plate,
      • Galvanized sheet, Copper sheet
      • titanium plates,aluminum sheet,etc
      • demo12
      • demo13
      • demo14

      產品概述

      1. Whole appearance, with reasonable mechanical structure, leveler, feeding, and grooves running smoothly, all are in  one production line.
      2. The letter each folding edge and angle are perfect,which are suitable for lot production.
      3. Compared to traditional production,CNC and standardized production, greatly improve production efficiency .
      4. This machine is based on Chinese letters and many years’ practical experience,independent research and development of software and hardware systems,complete with its own intellectual property.
      5. Grooving tool with traditional straight groove structure, a strong driving force hydraulic system,reasonable  structure, high hardness, especially the White steel ,can achieve high accuracy requirements.
